Product Description
| Rig weight | 8200/9100kg | Dimension(L×W×H) | 6750×2050×2400mm |
| Max thrust & pullback force | 225kN | Max thrust & pullback speed | 60m/min |
| Max torque | 6500N·m | Max rotation speed | 230r/min |
| Engine power | 113kW | Max mud pump flow | 250L/min |
| Caterpillar crawling speed | 2.5km/h | Max mud pump pressure | 8MPa |
| Entry drill angle | 12-20° | Max climbing gradient | 17° |
| Max back-reaming diameter | Φ900mm(soil depended) | Max crossing length | 300m(soil depended) |
