Product Description
Rig Weight | 9700/10200kg | Dimension(L×W×H) | 7300×2150×2250mm |
Max. Thrust & Pullback Force | 350/700kN | Max. Thrust & Pullback Speed | 40m/min |
Max. Torque | 12600N·m | Max. Rotation Speed | 140r/min |
Engine Power | 154kW | Max. Mud Pump Flow | 320L/min |
Caterpillar Crawling Speed | 3.5-6km/h | Max. Mud Pressure | 8MPa |
Entry Angle | 12°-22° | Max. Climbing Gradient | 18° |
Drill Rod Size | Ф73×3000mm | Drill Rod Box Capacity | 36pcs(4×9) |
Suggest Reaming Dia. | ≤ Ф900mm | Suggest Crossing Length | ≤ 400m |
